Printed circuit board power supply PMAS5 S15-S

AC/DCsingle-outputCE

Short description
AC/DC module PMAS5 S15-S designed for PCB mounting in vertical orientation. Rated power 5 W with an output voltage of 15 V. Wide input range accepts both AC and DC supplies.

Features

• Wide Input Range
• Smallest Dimensions
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial applications
• For PCB mounting
• Plug-and-play power supply unit for sensitive electrical subsystems

Technical Data
Power: 5 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 15 V
Output Current I1: 0.33 A
Efficiency: ≥72 %
Mounting Type: PCB mount (vertical mounting)
Dimensions: 42.0 x 30.0 x 18.2 mm
Weight: 50 g

Certifications
CE; UL/cUL; RoHS compliant; UKCA

Characteristics / technical specifications

• Power: 5 W
• AC Input Range: 90 – 264 V
• DC Input Range: 100 – 300 V
• Output Voltage (U1): 15 V
• Output Current (I1): 0.33 A
• Efficiency: ≥72 %
• Mounting Type: PCB mount (vertical mounting)
• Dimensions: 42.0 x 30.0 x 18.2 mm
• Weight: 50 g
• Overvoltage category: 2
• Certifications / compliance: CE, UL/cUL, RoHS, UKCA
