Chassis-mounted power supply PCMAS15 S05

AC/DCsingle-outputCE

Product Overview
AC/DC module PCMAS15 S05 — chassis-mounted AC/DC converter, nominal power 15 W, output voltage 5 V.

Features

• Wide input range (AC 90–264 V / DC 100–300 V)
• Compact dimensions (84.0 x 51.0 x 22.0 mm)
• Overvoltage category II

Applications

• Decentralised power supply for industrial systems
• Available for PCB mounting (PMAS) and for chassis mounting (PCMAS)
• Powering electronic and electrical circuits in process measurement & control, laboratory equipment, system and information technology

Datasheet / CAD
Datasheet (PDF) and 3D CAD drawing (STP) are available for this product.

Technical specifications

• Power: 12.5 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage U1: 5 V
• Output Current I1: 2.5 A
• Efficiency: ≥78 %
• Mounting Type: Chassis Mount
• Dimensions: 84.0 x 51.0 x 22.0 mm
• Weight: 100 g
