Chassis-mounted power supply PCMAS24 S48

AC/DCsingle-outputCE

Product Description
AC/DC power supply module for chassis mounting, nominal power 24 W. Designed for decentralised power supply in industrial applications with long service life and robust construction.

Features

• Wide input range
• Compact dimensions
• Overvoltage Category 2

Applications

• Decentralised power supply for industrial applications
• Available for PCB-mounting (PMAS) and chassis mounting (PCMAS)
• Supplying electronic and electrical circuits in process measurement and control technology, laboratory equipment, systems and IT

Technical Data (summary)
Power: 24 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 48 V
Output Current I1: 0.5 A
Efficiency: ≥83 %
Mounting Type: Chassis mount
Dimensions: 111.0 x 52.4 x 24.5 mm
Weight: 200 g

Approvals

• CE
• UL / cUL
• RoHS
• UKCA

Technical specifications

• Model: PCMAS24 S48
• Power: 24 W
• Output voltage: 48 V
• Output current: 0.5 A
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Efficiency: ≥83 %
• Mounting: Chassis mount
• Dimensions (L x W x H): 111.0 x 52.4 x 24.5 mm
• Weight: 200 g
