Printed circuit board power supply PMAS5 S15-L

AC/DCsingle-outputCE

Overview
AC/DC module PMAS5 S15-L — horizontal PCB-mount power module. Output power 5 W, nominal output voltage 15 V, suitable for decentralised power supply in industrial electronic systems.

Features

• Wide input range (AC and DC)
• Minimal footprint for space-constrained PCB designs
• Overvoltage category II

Applications

• Decentralised power supply for industrial equipment
• PCB-mounted power stage for control and sensing subsystems
• Plug-and-play power source for sensitive electronic modules

Certifications

• CE
• UL / cUL
• RoHS compliant
• UKCA

Technical Data
Power: 5 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 15 V
Output current I1: 0.33 A
Efficiency: ≥72 %
Mounting type: PCB mount
Dimensions: 42.6 x 32.6 x 17.0 mm
Weight: 50 g

Characteristics / Technical specifications

• Power: 5 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 15 V
• Output current: 0.33 A
• Efficiency: ≥72 %
• Mounting: PCB mount
• Dimensions: 42.6 x 32.6 x 17.0 mm
• Weight: 50 g
• Approvals / Compliance: CE, cUL/UL, RoHS, UKCA
