DIN rail power supply HSA15 D24

AC/DCdual-outputCE

Product Type
AC/DC power supply for DIN rail mounting.

Features

• Wide input range (AC 90 - 264 V / DC 100 - 300 V)
• Dual outputs +24 V / -24 V

Applications

• Power supply for DIN rail mounting
• For supplying electronic and electrical circuits in process measuring and control technology, laboratory equipment, as well as systems and information technology

Technical Data (table)
Power: 14.4 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 24 V
Output Current I1: 0.3 A
Output Voltage U2: -24 V
Output Current I2: 0.3 A
Efficiency: ≥68 %
Mounting Type: DIN Rail Mount
Dimensions: 29.0 x 115.0 x 76.0 mm
Weight: 250 g

Technical specifications

• Model: HSA15 D24
• Nominal power: 14.4 W
• AC input voltage range: 90 - 264 V
• DC input voltage range: 100 - 300 V
• Output 1 (U1): 24 V, 0.3 A
• Output 2 (U2): -24 V, 0.3 A
• Efficiency: ≥68 %
• Mounting: DIN rail
• Dimensions (W x H x D): 29.0 x 115.0 x 76.0 mm
• Weight: 250 g
