Printed circuit board power supply PMN30 S48

AC/DCsingle-outputCE

Product Overview
AC/DC Power Supply

Features

• Wide Input Range
• Isolation 3,3 kVrms

Applications

• Decentralised Power Supply for Industrial Applications
• Available for PCB-mounting (PMN) and for chassis mounting (PCMN)
• Plug-and-Play Power Supply Unit for Sensitive Electrical Subsystems

Documents
Datasheet available (PDF)

Technical Data PMN30 S48
Power: 31,2 W
AC Input: 36 - 60 V
DC Input: 36 - 70 V
Output Voltage U1: 48 V
Output Current I1: 0,65 A
Efficiency: 620% or greater
Mounting Type: PCB Mount
Dimensions: 90,5 x 65,5 x 33,5 mm
Weight: 340 g

Caractéristiques / spécifications techniques

• Power rating: 31,2 W
• Wide AC input range: 36 - 60 V
• Wide DC input range: 36 - 70 V
• Output voltage: 48 V
• Output current: 0,65 A
• Isolation: 3,3 kVrms
• Efficiency: 620% or greater
• Mounting: PCB mount (PMN series)
• Dimensions: 90,5 x 65,5 x 33,5 mm
• Weight: 340 g
• Certifications indicated: CE, RoHS, UKCA
