DIN rail power supply HSA15 S24

AC/DCsingle-outputCE

Product Overview
AC/DC power supply module for DIN-rail mounting. Compact 15 W unit with 24 V output designed for supplying electronic and electrical circuits in process measuring and control technology, laboratory equipment, systems and information technology.

Features

• Wide input range for AC and DC sources
• Compact DIN-rail housing
• Overload and short-circuit protection

Applications

• Power supply for DIN rail mounting
• Supplying electronic and electrical circuits in process measuring and control technology
• Laboratory equipment
• Systems and information technology

Approvals

• CE
• RoHS
• UKCA

Technical Data (table)
Power: 14.4 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 24 V
Output Current I1: 0.6 A
Efficiency: ≥78 %
Mounting Type: DIN rail mount
Dimensions: 29.0 x 115.0 x 76.0 mm
Weight: 250 g

Characteristics / Technical specifications

• Model: HSA15 S24 (24 V output)
• Rated power: ~15 W (14.4 W nominal)
• AC input range: 90–264 V
• DC input range: 100–300 V
• Output voltage: 24 V
• Output current: 0.6 A
• Efficiency: ≥78%
• Mounting: DIN rail
• Dimensions: 29.0 × 115.0 × 76.0 mm
• Weight: 250 g
• Datasheet: available (PDF)
