Chassis-mounted power supply PCMN30 S24

AC/DCsingle-outputCE

Overview
Low-voltage module: AC/DC power supply designed for chassis mounting (PCMN version). Provides regulated 24 V output for decentralised industrial and control applications. Illustration similar.

Features

• Wide input range suitable for AC and DC sources
• High isolation: 3.3 kVrms between primary and secondary
• Compact chassis-mount format for control cabinets and equipment racks
• Designed for plug-and-play integration with sensitive electrical subsystems

Applications

• Decentralised power supply for industrial control and automation systems
• Power source for measurement and monitoring equipment
• Use in cabinets, racks or standalone subsystems requiring chassis mounting

Datasheet
Datasheet and detailed product documentation available on the manufacturer's website (refer to product documentation section).

Certifications

• CE
• RoHS Compliance
• UKCA

Technical Data — PCMN30 S24

• Power: 31.2 W
• AC input range: 36 - 60 V
• DC input range: 36 - 70 V
• Output voltage (U1): 24 V
• Output current (I1): 1.3 A
• Efficiency: ≥77 %
• Isolation: 3.3 kVrms
• Mounting type: Chassis mount (PCMN)
• Dimensions (L × W × H): 120.0 × 65.0 × 33.0 mm
• Weight: 380 g
