DIN rail power supply HSA15 S12

AC/DCsingle-outputCE

Product
AC/DC power supply designed for DIN-rail mounting. Wide input range and 15.6 W output power class. Output voltage: 12 V.

Features

• Wide input range (AC: 90 - 264 V / DC: 100 - 300 V)
• Compact DIN-rail housing (29.0 x 115.0 x 76.0 mm)
• Output: 12 V, 1.3 A
• Efficiency ≥75 %

Applications

• Power supply for DIN-rail mounting
• Supplying electronic and electrical circuits in process measuring and control technology
• Laboratory equipment
• Systems and information technology

Certifications

• CE
• RoHS compliant
• UKCA

Technical Data (table)
Power: 15.6 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 12 V
Output Current I1: 1.3 A
Efficiency: ≥75 %
Mounting Type: DIN Rail Mount
Dimensions: 29.0 x 115.0 x 76.0 mm
Weight: 250 g

Technical specifications

• Power: 15.6 W
• AC input voltage range: 90 - 264 V
• DC input voltage range: 100 - 300 V
• Output voltage (U1): 12 V
• Output current (I1): 1.3 A
• Efficiency: ≥75 %
• Mounting: DIN Rail
• Dimensions (W x H x D): 29.0 x 115.0 x 76.0 mm
• Weight: 250 g
• Certifications: CE, RoHS, UKCA
