Printed circuit board power supply PMAS24 S12

AC/DCsingle-outputsingle-phase

Product overview
AC/DC power supply module PMAS24 S12, PCB-mount variant delivering 24 W output (12 V, 2.0 A). Designed for decentralized power distribution in industrial control, measurement and automation systems where compact PCB installation is required.

Features

• Wide input range: 90–264 VAC / 100–300 VDC
• Compact PCB-mount design for space-constrained assemblies
• Overvoltage category: 2

Applications

• Decentralised power supply for industrial applications
• PCB-mounted power for process instrumentation, control technology and laboratory equipment
• Integration in systems and information technology racks and embedded devices

Technical data
Power: 24 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 12 V
Output current I1: 2.0 A
Efficiency: ≥81 %
Mounting type: PCB mount
Dimensions: 75.55 x 50.05 x 22.5 mm
Weight: 150 g

Technical specifications

• Power: 24 W
• Input (AC): 90 - 264 V
• Input (DC): 100 - 300 V
• Output voltage: 12 V
• Output current: 2.0 A
• Efficiency: ≥81 %
• Mounting: PCB mount (PMAS)
• Dimensions: 75.55 x 50.05 x 22.5 mm
• Weight: 150 g
• Overvoltage category: 2
