Printed circuit board power supply PMAS10 S12

AC/DCsingle-outputCE

Product Overview
AC/DC module PMAS10 S12 for PCB mounting. Delivers 10 W output power with 12 V DC output up to 0.8 A. Input range covers 90–264 V AC and 100–300 V DC. Compact dimensions and low weight facilitate integration into control and measurement equipment.

Features

• Wide input voltage range: 90–264 V AC / 100–300 V DC
• Compact PCB-mount package (52.0 x 36.5 x 24.0 mm)
• Overvoltage category 2
• Efficiency ≥ 80 %

Applications

• Decentralized power supply for industrial equipment
• Chassis and PCB integration in control, measurement and automation systems
• Powering electronic circuits in laboratory and IT systems

Technical Data
Power: 10 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 12 V
Output current I1: 0.8 A
Efficiency: ≥80 %
Mounting type: PCB mount
Dimensions: 52.0 x 36.5 x 24.0 mm
Weight: 65 g

Characteristics / Technical specifications

• Power: 10 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage: 12 V
• Output current: 0.8 A
• Efficiency: ≥80 %
• Mounting: PCB mount
• Dimensions: 52.0 x 36.5 x 24.0 mm
• Weight: 65 g
• Overvoltage category: 2
