Printed circuit board power supply PMAS5 S24-L

AC/DCsingle-outputCE

Product description
AC/DC power module PMAS5 S24-L for PCB mounting. 5 W output power with 24 V nominal output; compact dimensions and wide input range make it suitable for decentralised industrial power supply and sensitive electronic subsystems.

Features

• Wide input range: 90–264 VAC / 100–300 VDC
• Compact PCB-mount design
• Overvoltage category 2
• Efficiency ≥74 %

Applications

• Decentralised power supply for industrial equipment
• PCB-mounted power for control and communication boards
• Plug-and-play power source for sensitive electrical subsystems

Downloads (available on the product page)

• Datasheet (PDF)
• 3D CAD model (STEP)

Technical Data PMAS5 S24-L

• Power: 5 W
• AC input: 90–264 V
• DC input: 100–300 V
• Output voltage (U1): 24 V
• Output current (I1): 0.21 A
• Efficiency: ≥74 %
• Mounting: PCB mount
• Dimensions (L × W × H): 42.6 x 32.6 x 17.0 mm
• Weight: 50 g
• Overvoltage category: 2
