Printed circuit board power supply PMA30 S48

AC/DCsingle-outputCE

Product overview
AC/DC power supply module PMA30 S48 from MTM Power. Robust PCB-mounted AC/DC module with 48 V output. Designed for decentralized power supply in industrial applications, featuring a wide input range and high efficiency.

Features

• Wide input range
• Prepared for Class 1/2
• Overvoltage Category 2
• High efficiency (≥85 %)
• PCB mounting

Applications

• Decentralized power supply for industrial applications
• Available for PCB-mounting (PMA) and for chassis mounting (PCMA)
• Supplying electronic and electrical circuits in process measuring and control technology, laboratory equipment, systems and information technology

Technical data (excerpt)
Power : 28.8 W
AC Input : 90 - 264 V
DC Input : 100 - 300 V
Output Voltage U1 : 48 V
Output Current I1 : 0.6 A
Efficiency : ≥85 %
Mounting Type : PCB Mount
Dimensions : 90.5 x 65.5 x 33.5 mm
Weight : 340 g

Certifications / Compliance

• CE
• UL / cUL
• RoHS compliance
• UKCA

Characteristics / technical specifications

• Model: PMA30 S48
• Power: 28.8 W
• Output voltage: 48 V
• Output current: 0.6 A
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Efficiency: ≥85 %
• Mounting: PCB mount
• Dimensions (W x D x H): 90.5 x 65.5 x 33.5 mm
• Weight: 340 g
• Overvoltage category: 2
• Prepared for Class 1/2
• CERTS: CE, UL/cUL, RoHS, UKCA
