DIN rail power supply HMN30 S24

AC/DCsingle-outputCE

Product Overview
HMN30 S24 is an AC/DC power supply for DIN-rail mounting. It delivers 30 W output power with a 24 V DC output at 1.3 A. The unit features a wide input range and reinforced isolation, in a compact 35.0 x 113.0 x 70.0 mm housing suitable for industrial control panels.

Features

• Wide input range: 36–60 V AC / 36–70 V DC
• Isolation: 3.3 kVrms
• Efficiency ≥77 %
• Compact DIN-rail mounting form factor

Applications

• Power supply for DIN-rail mounted control and automation equipment
• Supplying electronic and electrical circuits in process measurement and control
• Laboratory equipment and IT systems

Technical Data HMN30 S24
Power: 30 W
AC Input: 36 - 60 V AC
DC Input: 36 - 70 V DC
Output Voltage U1: 24 V
Output Current I1: 1.3 A
Isolation: 3.3 kVrms
Efficiency: ≥77 %
Mounting Type: DIN-rail
Dimensions: 35.0 x 113.0 x 70.0 mm
Weight: 390 g

Datasheet
Datasheet available for download.

Technical specifications

• Power: 30 W
• AC Input: 36 - 60 V AC
• DC Input: 36 - 70 V DC
• Output Voltage: 24 V
• Output Current: 1.3 A
• Isolation: 3.3 kVrms
• Efficiency: ≥77 %
• Mounting Type: DIN-rail
• Dimensions: 35.0 x 113.0 x 70.0 mm
• Weight: 390 g
