DIN rail power supply HMA15 S15

AC/DCsingle-outputCE

Product overview
HMA15 S15 is a 15 W AC/DC DIN-rail power supply with a 15 V DC output. It is designed for DIN-rail mounting in industrial control, measurement and information technology systems.

Features

• Wide input range: 90–264 VAC / 100–300 VDC
• Compact DIN-rail housing (35.0 x 113.0 x 70.0 mm)
• Output: 15 V, 1.0 A

Applications

• Power supply for DIN-rail mounted equipment
• Supplying electronic and electrical circuits in process control, laboratory equipment, systems and information technology

Certifications

• CE
• UL/cUL
• RoHS
• UKCA

Technical Data (table)
Power: 15 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 15 V
Output current I1: 1.0 A
Efficiency: ≥73%
Mounting type: DIN-rail mount
Dimensions: 35.0 x 113.0 x 70.0 mm
Weight: 390 g

Technical characteristics / specifications

• Power: 15 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 15 V
• Output current: 1.0 A
• Efficiency: ≥73%
• Mounting type: DIN-rail mount
• Dimensions: 35.0 x 113.0 x 70.0 mm
• Weight: 390 g
