Chassis-mounted power supply PCMAS15 S48

AC/DCsingle-outputCE

Product overview
PCMAS15 S48 is an AC/DC power supply module for chassis mounting that delivers a nominal output voltage of 48 V. It is intended for decentralized power distribution in industrial applications and is available in chassis-mount (PCMAS) and PCB-mount (PMAS) variants. The design targets compact installation and long service life.

Features

• Wide input range: AC 90–264 V / DC 100–300 V
• Compact dimensions: 84.0 x 51.0 x 22.0 mm
• Overvoltage category II
• Rated power approx. 15 W (listed power 14.4 W)
• Output voltage 48 V, output current 0.3 A
• Efficiency ≥83 %
• Chassis mount (PCMAS); PCB-mount option (PMAS)

Applications

• Decentralised power supply for industrial installations
• Powering electronic/electrical circuits in process measurement and control systems
• Laboratory equipment
• Systems and information technology

Downloads
Datasheet (PDF) and 3D CAD drawing (STP) are available for download.

Technical Data (table)
Power: 14.4 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 48 V
Output Current I1: 0.3 A
Efficiency: ≥83 %
Mounting Type: Chassis Mount
Dimensions: 84.0 x 51.0 x 22.0 mm
Weight: 100 g

Technical specifications

• Power: 14.4 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 48 V
• Output current: 0.3 A
• Efficiency: ≥83 %
• Mounting: Chassis mount
• Dimensions (L x W x H): 84.0 x 51.0 x 22.0 mm
• Weight: 100 g
• Overvoltage category: 2
