Printed circuit board power supply PMAS5 S05-S

AC/DCsingle-outputCE

Overview
AC/DC power supply module for PCB mounting. Compact 5 W output module providing 5 V at 1.0 A, designed for vertical PCB installation. Engineered for reliable continuous operation in decentralised industrial power architectures.

Features

• Wide input range: AC 90–264 V and DC 100–300 V
• Compact PCB-mount format (42.0 x 30.0 x 18.2 mm)
• Overvoltage Category II
• Output: 5 V / 1.0 A, 5 W total power
• Efficiency ≥70%

Applications

• Decentralised power supply for industrial control and automation
• PCB-mounted power source for embedded and electronic subsystems
• Plug-and-play supply for sensitive electronics requiring regulated 5 V

Technical Data PMAS5 S05-S

• Power: 5 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage U1: 5 V
• Output current I1: 1.0 A
• Efficiency: ≥70%
• Mounting type: PCB mount (vertical)
• Dimensions: 42.0 x 30.0 x 18.2 mm
• Weight: 50 g

Technical specifications

• Power: 5 W
• AC input voltage range: 90 - 264 V
• DC input voltage range: 100 - 300 V
• Output voltage: 5 V
• Output current: 1.0 A
• Efficiency: ≥70%
• Mounting: PCB mount
• Dimensions: 42.0 x 30.0 x 18.2 mm
• Weight: 50 g
