Chassis-mounted power supply PCMAS24 S12

AC/DCregulatedsingle-output

Short description
AC/DC module PCMAS24 S12 provides a regulated 12 V output with 24 W power in a chassis-mount format, intended for decentralised power supply in industrial and instrumentation environments.

Features

• Wide input range: 90–264 VAC / 100–300 VDC
• Compact chassis design (111.0 x 52.4 x 24.5 mm)
• Overvoltage category II

Applications

• Decentralised power supply for industrial automation and control systems
• Available in PCB-mount (PMAS) and chassis-mount (PCMAS) variants
• Powering electronic circuits in process measurement, laboratory equipment and IT systems

Technical data (table)

• Power: 24 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage (U1): 12 V
• Output current (I1): 2.0 A
• Efficiency: ≥81 %
• Mounting type: Chassis mount
• Dimensions: 111.0 x 52.4 x 24.5 mm
• Weight: 200 g

Specifications

• Power: 24 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage (U1): 12 V
• Output current (I1): 2.0 A
• Efficiency: ≥81 %
• Mounting type: Chassis mount
• Dimensions: 111.0 x 52.4 x 24.5 mm
• Weight: 200 g
