Printed circuit board power supply PMN30 S15

AC/DCsingle-outputCE

Product Overview
PMN30 S15 is a 30 W AC/DC power supply module for PCB mounting. It is intended for decentralised industrial power distribution and for powering sensitive electronic subsystems. Illustration similar.

Features

• Wide input range (AC 36–60 V / DC 36–70 V)
• High isolation voltage: 3.3 kVrms
• Output: 15 V, 2.0 A
• Efficiency ≥ 75 %

Applications

• Decentralised power supply in industrial equipment
• PCB mounting (PMN) or chassis mounting variant (PCMN)
• Powering sensitive electrical subsystems and control electronics

Technical Data
Power: 30 W
AC input: 36 - 60 V
DC input: 36 - 70 V
Output voltage U1: 15 V
Output current I1: 2.0 A
Efficiency: ≥75 %
Mounting type: PCB mount
Dimensions: 90.5 x 65.5 x 33.5 mm
Weight: 340 g

Certifications / Compliance

• CE
• RoHS
• UKCA

Characteristics / Technical specifications

• Model family: PMN/PCMN30 low-voltage modules
• Isolation voltage: 3.3 kVrms
• Nominal power: 30 W
• Supported input types: AC and DC within specified ranges
• Mounting: PCB mount (PMN); chassis option available (PCMN)
• Intended use: decentralised industrial power supply, sensitive subsystem supply
