DIN rail power supply HMA15 D15

AC/DCdual-outputCE

Product overview
DIN-rail AC/DC power supply module HMA15 D15 providing bipolar outputs ±15 V with approximately 13.5 W total output. Compact converter designed for DIN-rail mounting and intended for industrial instrumentation, laboratory equipment and information systems requiring bipolar low-power supplies.

Features

• Wide input range
• AC input: 90–264 V
• DC input: 100–300 V
• Dual bipolar outputs: +15 V and -15 V
• Output currents: +0.5 A (positive), -0.4 A (negative)
• Rated power: 13.5 W (product name indicates ~15 W)
• Efficiency: ≥66%
• DIN-rail mounting (EN standard profile)
• Compact dimensions and low weight
• Suitable for industrial and instrumentation environments

Applications

• Power supply for DIN-rail mounted control cabinets
• Supplying electronic circuits in process measurement & control systems
• Laboratory instruments and test equipment
• Embedded systems and information technology devices

Downloads

• Datasheet available (PDF)

Certifications / Compliance

• CE
• cUL/UL
• RoHS
• UKCA

Technical specifications

• Power: 13.5 W
• AC input: 90–264 V
• DC input: 100–300 V
• Output 1: +15 V / 0.5 A
• Output 2: -15 V / 0.4 A
• Efficiency: ≥66%
• Mounting type: DIN-rail mount
• Dimensions (W x H x D): 35.0 x 113.0 x 70.0 mm
• Weight: 390 g
