Printed circuit board power supply PMAS15 S24

AC/DCsingle-outputCE

Product Overview
AC/DC power supply with 145 W nominal output. PCB-mount variant PMAS15 S24 with 24 V DC output. Compact footprint for decentralized power distribution in industrial measurement and control systems. Illustration similar.

Features

• Wide input range (AC 90–264 V, DC 100–300 V)
• Compact dimensions for space-constrained PCB integration
• Overvoltage category II

Applications

• Decentralised power supply for industrial automation and control equipment
• PCB-mounted power module for embedded power designs
• Supply for electronic circuits in process measurement, laboratory equipment and IT systems

Technical Data (table)
Power: 145 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 24 V
Output current I1: 0.6 A
Efficiency: ≥83%
Mounting type: PCB mount
Dimensions: 50.8 x 50.8 x 20.0 mm
Weight: 100 g

Technical specifications

• Power: 145 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage (U1): 24 V
• Output current (I1): 0.6 A
• Efficiency: ≥83%
• Mounting type: PCB mount
• Dimensions: 50.8 x 50.8 x 20.0 mm
• Weight: 100 g
