Printed circuit board power supply PMAS5 S05-L

AC/DCsingle-outputCE

Product Overview
AC/DC module PMAS5 S05-L — horizontal PCB-mount power module, 5 W output power, fixed 5 V output. Compact dimensions and wide input range for decentralised industrial power supply.

Features

• Wide input range (AC and DC)
• Compact footprint for space-constrained PCB designs
• Overvoltage category II

Applications

• Decentralised power supply for industrial equipment
• PCB-mounting in control and automation boards
• Plug-and-play power stage for sensitive electronic subsystems

Downloads

• Datasheet available
• 3D CAD drawing available (STEP)

Technical Data (table)
Power: 5 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 5 V
Output current I1: 1.0 A
Efficiency: ≥70 %
Mounting type: PCB mount
Dimensions: 42.6 x 32.6 x 17.0 mm
Weight: 50 g

Certifications / Conformities

• CE
• UL/cUL
• RoHS
• UKCA

Technical specifications

• Power: 5 W
• AC input range: 90–264 V
• DC input range: 100–300 V
• Output voltage: 5 V
• Rated output current: 1.0 A
• Typical efficiency: ≥70 %
• Mounting: PCB mount
• Dimensions (L x W x H): 42.6 x 32.6 x 17.0 mm
• Weight: 50 g
• Overvoltage category: II
• Typical use cases: decentralised industrial power, PCB integration, power stage for sensitive electronics
