Printed circuit board power supply PMAS15 S12

AC/DCsingle-outputCE

Product overview
AC/DC power module PMAS15 S12 designed for PCB mounting, delivering 15 W output power at 12 V. Compact dimensions and wide input range suit decentralized power supply in industrial control, instrumentation and information systems.

Features

• Wide input range: 90–264 VAC and 100–300 VDC
• Compact PCB-mount design (50.8 x 50.8 x 20.0 mm)
• High efficiency (≥81 %) and Overvoltage Category 2

Applications

• Decentralized power supply for industrial automation and process control
• Powering electronic circuits in laboratory and measurement equipment
• PCB-mounted power solution for control cabinets and IT systems

Technical Data (summary)
Power: 15 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 12 V
Output current I1: 1.25 A
Efficiency: ≥81 %
Mounting type: PCB mount
Dimensions: 50.8 x 50.8 x 20.0 mm
Weight: 100 g

Downloads
Datasheet (PDF) and 3D CAD drawing (STP) available.

Technical specifications

• Power: 15 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 12 V
• Output current: 1.25 A
• Efficiency: ≥81 %
• Mounting: PCB mount
• Dimensions: 50.8 x 50.8 x 20.0 mm
• Weight: 100 g
• Certifications / Compliance: CE, UL/cUL, RoHS, UKCA
