Printed circuit board power supply PMAS15 S48

AC/DCsingle-outputCE

Product Overview
AC/DC power module PMAS15 S48 for PCB mounting, delivering 15 W output at 48 V. Compact size and wide input range make it suitable for decentralised power supply in industrial, measurement and control applications.

Features

• Wide input voltage range: 90–264 VAC and 100–300 VDC
• Compact PCB-mount design (50.8 x 50.8 x 20.0 mm)
• Overvoltage category II
• Efficiency ≥83%

Applications

• Decentralised power supply for industrial control and automation
• PCB-mounted power for instrumentation and process control electronics
• Laboratory equipment, systems and IT applications

Downloads

• Datasheet (PDF)
• 3D CAD drawing (STP)

Technical specifications

• Power: 15 W
• AC input: 90 - 264 V
• DC input: 100 - 300 V
• Output voltage U1: 48 V
• Output current I1: 0.3 A
• Efficiency: ≥83%
• Mounting type: PCB mount
• Dimensions: 50.8 x 50.8 x 20.0 mm
• Weight: 100 g
