Printed circuit board power supply PMAS15 S15

AC/DCsingle-outputCE

Product Overview
AC/DC power supply module for PCB mounting (PMAS series). Nominal power: 15 W. Output voltage: 15 V. Intended for PCB assembly in industrial control, instrumentation and IT equipment.

Key Features

• Wide input range: AC 90–264 V / DC 100–300 V
• Compact dimensions: 50.8 x 50.8 x 20.0 mm
• Overvoltage category II
• Efficiency ≥81 %
• Output current: 1.0 A
• Mounting type: PCB mount (PMAS series)

Applications

• Decentralised power supply for industrial applications
• Supply of electronic and electrical circuits in process measuring and control technology
• Laboratory equipment
• Systems and information technology
• Available variants: PCB-mounting (PMAS) and chassis mounting (PCMAS)

Technical Data
Power: 15 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 15 V
Output Current I1: 1.0 A
Efficiency: ≥81 %
Mounting Type: PCB mount
Dimensions: 50.8 x 50.8 x 20.0 mm
Weight: 100 g

Certifications / Compliance

• CE
• cULus (UL/cUL)
• RoHS compliant
• UKCA

Downloads & 3D
Datasheet (PDF) and 3D CAD drawing are available for this product.

Technical specifications

• Model: PMAS15 S15
• Power: 15 W
• Output voltage: 15 V
• Output current: 1.0 A
• Efficiency: ≥81 %
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Mounting type: PCB mount (PMAS series)
• Dimensions: 50.8 x 50.8 x 20.0 mm
• Weight: 100 g
• Overvoltage category: 2
• Certifications: CE, cULus, RoHS, UKCA
