Printed circuit board power supply PMAS24 S15

AC/DCsingle-outputCE

Product Overview
AC/DC module PMAS24 S15 provides 24 W output at 15 V for PCB mounting. Designed for decentralised industrial and laboratory power supply, it accepts a wide AC and DC input range and delivers high efficiency for reliable operation.

Features

• Wide input range: AC 90–264 V and DC 100–300 V
• Compact dimensions for its power class (75.55 x 50.05 x 22.5 mm)
• Overvoltage category II
• High efficiency (≥81%) to reduce thermal dissipation
• PCB mounting for direct integration into assemblies

Applications

• Decentralised power supply for industrial equipment
• Powering electronics in process measurement and control systems
• Laboratory and test equipment
• Systems and information technology

Technical Data (PMAS24 S15)
Power | 24 W
AC Input | 90 - 264 V
DC Input | 100 - 300 V
Output Voltage U1 | 15 V
Output Current I1 | 1.6 A
Efficiency | ≥81 %
Mounting Type | PCB mount
Dimensions | 75.55 x 50.05 x 22.5 mm
Weight | 150 g

Characteristics / Technical specifications

• Model: PMAS24 S15
• Rated output power: 24 W
• Output voltage: 15 V
• Maximum output current: 1.6 A
• Input ranges: AC 90–264 V, DC 100–300 V
• Efficiency: ≥81 %
• Mounting: PCB mount
• Dimensions (L x W x H): 75.55 x 50.05 x 22.5 mm
• Weight: approx. 150 g
• Approvals / Compliance: CE, cUL/UL, RoHS, UKCA
