Chassis-mounted power supply PCMN15 S15

AC/DCsingle-outputCE

Overview
PCMN15 S15 is a 15 W AC/DC decentralised power supply module available in PCB-mount (PMN) and chassis-mount (PCMN) variants. It is designed to supply electronic and electrical circuits in process measurement and control technology, laboratory equipment, and IT systems.

Features

• Wide input range (AC: 30–60 V, DC: 30–70 V)
• Isolation 3.3 kVrms
• Efficiency ≥73 %

Applications

• Decentralised power supply for industrial installations
• Powering process instrumentation and control technology
• Suitable for laboratory equipment, systems and information technology
• Available for PCB-mount (PMN) and chassis-mount (PCMN)

Technical data

• Power: 15 W
• AC input: 30 - 60 V
• DC input: 30 - 70 V
• Output voltage U1: 15 V
• Output current I1: 1.0 A
• Efficiency: ≥73 %
• Isolation: 3.3 kVrms
• Mounting type: Chassis mount (PCMN variant)
• Dimensions: 110.0 x 50.8 x 23.0 mm
• Weight: 200 g

Certifications / Compliance

• CE
• RoHS
• UKCA
