Printed circuit board power supply PMAS24 S24

AC/DCsingle-outputCE

Product description
AC/DC module PMAS24 S24 — 24 W PCB-mount power supply with 24 V output. Compact module for decentralised supply of electronic and electrical circuits, designed for industrial applications with wide input range and standard approvals.

Features

• Wide input range: 90–264 V AC / 100–300 V DC
• Compact PCB-mount module (75.55 x 50.05 x 22.5 mm)
• Overvoltage category II
• Efficiency ≥83 %
• Output: 24 V, 1.0 A

Applications

• Decentralised power supply for industrial control and automation
• Process measurement and control technology and laboratory equipment
• Embedded systems and information technology

Technical data
Power: 24 W
AC input: 90 - 264 V AC
DC input: 100 - 300 V DC
Output voltage U1: 24 V
Output current I1: 1.0 A
Efficiency: ≥83 %
Mounting type: PCB mount
Dimensions: 75.55 x 50.05 x 22.5 mm
Weight: 150 g

Certifications

• CE
• UL / cUL
• RoHS
• UKCA
