Printed circuit board power supply PMAS10 S15

AC/DCsingle-outputCE

Short description
AC/DC power module PMAS10 S15 for PCB mounting. 10 W output power with fixed 15 V output. Wide input range compatible with industrial AC and DC supplies.

Features

• Wide input range: 90 - 264 VAC / 100 - 300 VDC
• Compact PCB-mount package (52.0 x 36.5 x 24.0 mm)
• Overvoltage Category 2
• Active inrush current limitation

Applications

• Decentralised power supply for industrial equipment
• Chassis mounting and embedded systems
• Supply for electronic circuits in process control, laboratory equipment and IT systems

Technical data
Power: 10 W
AC Input: 90 - 264 V
DC Input: 100 - 300 V
Output Voltage U1: 15 V
Output Current I1: 0.67 A
Efficiency: ≥80 %
Mounting Type: PCB mount
Dimensions: 52.0 x 36.5 x 24.0 mm
Weight: 65 g

Approvals / Compliance

• CE
• UL / cUL
• RoHS compliant
• UKCA

Characteristics / Technical specifications

• Power: 10 W
• AC input range: 90 - 264 V
• DC input range: 100 - 300 V
• Output voltage: 15 V (U1)
• Output current: 0.67 A (I1)
• Efficiency: ≥80 %
• Mounting type: PCB mount
• Dimensions: 52.0 x 36.5 x 24.0 mm
• Weight: 65 g
