DIN rail power supply HMA30 S15

AC/DCsingle-outputCE

Product Overview
DIN rail module HMA30 S15: AC/DC power supply providing 30 W output at 15 V. Compact housing designed for DIN-rail mounting, suitable for industrial control cabinets and measurement systems.

Features

• Wide input range (AC 90 - 264 V / DC 100 - 300 V)
• Single 15 V output, 2 A
• Efficiency ≥82 %
• Compact dimensions for panel integration
• DIN rail mounting

Applications

• Power supply for DIN-rail installations
• Supplying electronic and electrical circuits in process measurement and control technology
• Laboratory equipment and IT systems

Technical Data HMA30 S15 (table)
Power : 30 W
AC Input : 90 - 264 V
DC Input : 100 - 300 V
Output Voltage U1 : 15 V
Output Current I1 : 2 A
Efficiency : ≥82 %
Mounting Type : DIN Rail Mount
Dimensions : 35.0 x 113.0 x 70.0 mm
Weight : 390 g

Technical specifications

• Power: 30 W
• AC Input: 90 - 264 V
• DC Input: 100 - 300 V
• Output Voltage U1: 15 V
• Output Current I1: 2 A
• Efficiency: ≥82 %
• Mounting Type: DIN Rail Mount
• Dimensions: 35.0 x 113.0 x 70.0 mm
• Weight: 390 g
