Printed circuit board power supply PMA30 S05

AC/DCsingle-outputCE

Product overview
AC/DC power supply for PCB mounting. Designed for decentralized power distribution in industrial applications. Output voltage: 5 V. Rated power: 30 W.

Features

• Wide input range
• Prepared for Class 1/2 installation
• Overvoltage category II

Applications

• Decentralized power supply for industrial systems
• Available for PCB mounting (PMA) and chassis mounting (PCMA)
• Powering electronic and electrical circuits in process measurement and control, laboratory equipment, systems and IT

Technical data (table)
Power: 30 W
AC input: 90 - 264 V
DC input: 100 - 300 V
Output voltage U1: 5 V
Output current I1: 6 A
Efficiency: 75% or greater
Mounting type: PCB mount
Dimensions (L x W x H): 90.5 x 65.5 x 33.5 mm
Weight: 340 g

Technical specifications

• Power: 30 W
• AC input voltage range: 90 - 264 V
• DC input voltage range: 100 - 300 V
• Output voltage (U1): 5 V
• Output current (I1): 6 A
• Efficiency: 75% or greater
• Mounting type: PCB mount
• Dimensions (L x W x H): 90.5 x 65.5 x 33.5 mm
• Weight: 340 g
• Approvals / Compliance: CE, cULus, RoHS, UKCA (as indicated)
