Time-of-flight sensor XTOF-M-100

Product Overview
The XTOF-M-100 is a miniaturized 3D time-of-flight (ToF) camera based on the XTOF-100-A ToF chip and an integrated LED illumination. It is delivered fully calibrated and provides per-pixel distance measurements via a standard Rx/Tx UART at 1 MBit/s.

Specifications

• Range: 0.1 to 3 m
• Resolution: 8×8 (64 ToF pixels)
• Field of view: 12° horizontal / 12° vertical
• Frame rate: >50 fps (performance maintained under full sunlight)

Features

• Low power consumption
• Ambient-light tolerant
• Compact package with flexible mounting options
• Advanced filtering and processing algorithms
• Simple UART data interface (Rx/Tx)

Applications

• Short-range distance measurement (centimetres to meters)
• High-end robotics and automation systems
• Rotating scanners and SLAM mapping
• Proximity sensing and presence detection
• Custom OEM integration

Technical specifications

• Range: 0.1 to 3 m
• Pixels: 64 ToF pixels (8×8)
• Field of view: 12° horizontal / 12° vertical
• Frame rate: >50 fps
• Interface: Rx/Tx UART, 1 MBit/s
• Illumination: integrated LED
• Calibration: delivered fully calibrated
