Silicon photodiode VTB6061CIEH

Description
The VTB6061CIEH is a silicon photodiode in a hermetic TO-8 flat-window package with an integrated visible filter that closely matches the human eye photopic response. It provides a large 37.7 mm² active area, very high shunt resistance and very low dark current, making it suitable for precision light measurement in photovoltaic mode or with a small reverse bias.

General
The VTB6061CIEH features a 37.7 mm² active area optimized for photometric applications. It is primarily intended for photovoltaic operation but can be used with a small reverse bias. The device's high shunt resistance minimizes offset errors in high-gain trans-impedance amplifier circuits.

Features & Benefits

• Visible spectral response matched to human eye (photopic)
• 1%–2% linearity over 7 to 9 decades
• Very low dark current (≤2 nA at 2 V reverse bias)
• Very high shunt resistance for low offset in high-gain designs
• RoHS compliant

Applications

• Ambient light sensing
• Light meters and photometers
• Flame monitoring
• Photometry and laboratory light measurement

Specifications

• Active area = 37.7 mm²
• Photometric sensitivity = Minimum 75 nA/fc at 1 fc
• Dark current = Maximum 2 nA at 2 V reverse bias
• Junction capacitance = Typical 8.0 nF at 0 V bias
• Spectral range = 460 nm to 675 nm
• Peak spectral response = 555 nm
• Angular response = ±55° at 50% response
