Lamp light source FX-1100

xenon lampinfraredultraviolet

Product overview The Excelitas FX-1100 Series short-arc xenon flashlamps are unconfined arc devices that produce microsecond-duration broadband light pulses with high radiant intensity. Their arc stability and service life make them suitable for precision photometry, radiometry and spectroradiometry.

Key features

• Unconfined arc design producing microsecond-duration broadband light pulses
• High radiant intensity with stable arc behavior and extended operating life
• Power range from 10 W (glass-bodied) to 20 W (metal can)
• FX-1160 sub‑series metal can includes an internal reflector, increasing usable light output by approximately 40% versus non-reflector lamps
• Capable of high repetition-rate operation
• Continuous spectral output from ultraviolet through visible to infrared
• Applications: precision photometry, radiometry, spectroradiometry

Additional information The FX-1100 Series provides a variety of lamp formats and window materials for applications requiring stable, high-intensity short-arc xenon flashes and consistent spectral output across UV–IR regions.

Technical specifications

• Arc lengths (mm): 1.5, 3.0
• Window materials and spectral ranges: Borosilicate (≈225 nm–1100 nm+), UV glass (≈190 nm–1100 nm+), MgF2 (≈120 nm–1100 nm+)
• Power range: 10 W (glass-bodied) to 20 W (metal can)
• Sub-series: FX-1160 metal can lamp with internal reflector (approx. +40% usable light output vs. non-reflector)
• Spectrum: continuous from ultraviolet through visible to infrared
• Typical applications: precision photometry, radiometry, spectroradiometry
